Tiny NFC 18W
Tiny NFC 18W
Characteristic
NFC current setting
Protection type: short circuit/overload/no-load/Class II
Protection level: IP20
Start time: ≤ 0.5S (230VAC, full load)
Working temperature: -20~50 ℃
Storage temperature: -20~85 ℃
Application: Tube lights, panel lights
Size: 55 * 25mm (R * H)
Parameter specifications
Model:R18C150-700N-N
NFC current setting
Power:18W: 150-700mA
Warranty: 5 years
File Download：
Phone:
Email:
Enquire Now
PRODUCT DESCRIPTION
Parameter reading:
| Model | Output Current (*Typical) |
Input Current |
Input Power |
Output Power Range |
PF | Efficiency | Output Voltage |
No load Voltage |
| R18C150-700N-N | 150mA | 0.07A | 10W | 0.375-6.75W | 0.88 | 80% | 2.5-45V | 60V |
| 200mA | 0.08A | 11W | 0.5-9W | 0.92 | 82% | 2.5-45V | 60V | |
| 250mA | 0.08A | 14W | 0.625-11.25W | 0.92 | 82% | 2.5-45V | 60V | |
| 300mA | 0.09A | 17W | 0.75-13.5W | 0.92 | 84% | 2.5-45V | 60V | |
| 350mA | 0.11A | 19W | 0.875-15.75W | 0.92 | 84% | 2.5-45V | 60V | |
| 400mA | 0.13A | 20.5W | 1-18W | 0.92 | 85% | 2.5-45V | 60V | |
| 450mA | 0.13A | 21W | 1.125-20.25W | 0.92 | 85% | 2.5-40V | 60V | |
| 500mA | 0.11A | 19W | 1.25-16W | 0.92 | 84% | 2.5-32V | 60V | |
| 550mA | 0.13A | 21W | 1.375-17.6W | 0.92 | 85% | 2.5-32V | 60V | |
| 600mA | 0.13A | 20W | 1.5-16.8W | 0.92 | 84% | 2.5-28V | 60V | |
| 650mA | 0.13A | 22W | 1.625-18.2W | 0.92 | 85% | 2.5-28V | 60V | |
| 700mA | 0.13A | 22W | 1.75-17.5W | 0.92 | 84% | 2.5-25V | 60V |
