Tiny NFC Casambi 10W 15W
Tiny NFC Casambi 10W 15W
Characteristic
Dimming type: CASAMBI
Current Setting：NFC
Protection type: short circuit/overload/no-load/Class II
IP Grade: IP20
Start time: ≤ 1s (230VAC, full load)
Working temperature: -20~50 ℃
Storage temperature: -35~85 ℃
Application: Tube lights, panel lights
Size: 64.5*40*23mm (L*W*H)
Parameter specifications
Modle: C10C150-500N-C / C15C100-700N-C
Power: 10W: 150-500mA / 15W: 100-700mA
Warranty: 5 years
File Download：
Phone:
Email:
Enquire Now
PRODUCT DESCRIPTION
Parameter reading:
| Model | Output Current (*Typical) |
Input Current |
Input Power |
Output Power Range |
PF | Efficiency | Output Voltage |
No load Voltage |
| C10C150-500N-C | 150mA | 0.05A | 8.8W | 0.38-6.75W | 0.75 | 84% | 2.5-45V | 59V |
| 200mA | 0.07A | 11.5W | 0.50-9.00W | 0.85 | 85% | 2.5-45V | 59V | |
| 250mA | 0.07A | 12.8W | 0.63-10.00W | 0.88 | 85% | 2.5-40V | 59V | |
| 300mA | 0.07A | 12.5W | 0.75-9.90W | 0.88 | 84% | 2.5-33V | 59V | |
| 350mA | 0.07A | 12.5W | 0.88-9.80W | 0.88 | 84% | 2.5-28V | 59V | |
| 400mA | 0.07A | 12.6W | 1.00-10.00W | 0.88 | 84% | 2.5-25V | 59V | |
| 450mA | 0.07A | 11.5W | 1.13-9.00W | 0.88 | 84% | 2.5-20V | 59V | |
| 500mA | 0.07A | 12.6W | 1.25-10.00W | 0.88 | 84% | 2.5-20V | 59V |
| Model | Output Current (*Typical) |
Input Current |
Input Power |
Output Power Range |
PF | Efficiency | Output Voltage |
No load Voltage |
| C15C100-700N-C | 100mA | 0.04A | 6.5W | 0.25-4.50OW | 0.6 | 83% | 2.5-45V | 59V |
| 200mA | 0.07A | 11.5W | 0.50-9.00W | 0.8 | 85% | 2.5-45V | 59V | |
| 300mA | 0.10A | 16.8W | 0.75-13.50W | 0.85 | 86% | 2.5-45V | 59V | |
| 400mA | 0.11A | 18.8W | 1.00-15.20W | 0.92 | 85% | 2.5-38V | 59V | |
| 500mA | 0.11A | 18.6W | 1.25-15.00W | 0.92 | 85% | 2.5-30V | 59V | |
| 600mA | 0.11A | 18.5W | 1.50-15.00W | 0.92 | 85% | 2.5-25V | 59V | |
| 700mA | 0.11A | 19.0W | 1.75-15.4W | 0.92 | 85% | 2.5-22V | 59V |
Categories：
Tiny
Keyword：
Tiny NFC Casambi 10W 15W
Kegu Power is ISO 9001:2015 certified and adopts Barcode Trace-abilitySystem for best quality control, and also has advanced ERP managementsystem to optimize the internal operation processes, and continuouslyenhance management performance and product competitiveness.Wealso Broad in external consultants and build fully automated productionline. Our products are engineered up to the utmost standard and passworldwide certificates such as CE,TUV,ENEC, CB, RoHS, UL and ccC ect.
